A top of the line 500w electric mountain bike with the air suspension fork and rear suspension, a removable power battery with 672Wh capacity, and 27.5" * 2.8" Chaoyang tires that can tackle almost any terrain.
WHAT'S IN THE PACKAGE
Delivered with 85% assembled:
Ebike & battery;
Original charger & adapator;
Front tire & quick release;
Pedals, saddle & seat post;
Screws and tools for assembly.
1/2 - Electronic System
500W Hub Motor
Eahora design the internal structure of the motor. All the while the 500 Watt high-speed brushless motor can produce speeds up fast.
Max Torque: 45N.m
2/2 - Electronic System
48V 14Ah Battery
The battery is a crucial component of the electric bike. AM100 batteries ensure high safety and long life, which makes them vital for your ride to be longlasting and enjoyable! Removable design means they're easy enough even if you don't have any experience installing bikes.
Throtte Mode Range: 24 - 26 Miles
PAS Mode Range: 34 - 37 Miles
- 1. MOTOR
- 2. BATTERY
Size and Geometry
Recommended Rider Height: 5'9" - 6'4" or 175CM - 195CM
Ⓐ - Total Length: 76.3" or 194CM
Ⓑ - Wheel Base: 47.2" or 120CM
Ⓒ - Seat Height: 35.0" - 42.5" or 89CM - 108CM
Ⓓ - Handlebar Height: 45.6" or 116CM
Ⓔ - Rim Diameter: 23.6" or 60CM
Ⓕ - Standover: 29.5" or 75CM
Ⓖ - Reach Distance: 16.1" or 41CM
Ⓗ - Chain Stay Length: 21.2" or 54CM
Ⓘ - Seat Angle: 66.8°
Ⓙ - Seat Tube Length: 17.7" or 450MM
Ⓚ - Bike Width: 25.9" or 66CM
Ⓛ - Top Tube Length: 20.8" or 53CM
To ensure uninterrupted suppluying and shipping, some parts may differ from those listed. Rest assured, our engineers rigorously test each component to guarantee quality and compatibility.
Class 3 ebike with throttle and pedal asssit functions.
60.6lbs in total with the battery.
Range per Charge
24 - 26 miles on throttle mode. 34 - 37 miles on pas mode.
Recomend rider weight within 240lbs.
RW05 500W DC hub motor, cassette; Max torque: 55N.M.
48V 14AH 672WH lithium battery.
48V, 20 ± 0.5A; 9MOS.
54.6V ~ 2A smart charger; input 100-240V 50/60HZ.
3" portrait color display(YL-80C-C), IP65 Waterproof; brightness: 100CD/M2.
Front light 48V LED light; rear relfector.
Water resistant connectors and wiring harness.
6061 aluminum; frame size: 27.5" * 18".
180mm front and rear hydraulic disc brakes.
Aluminum alloy comfort grip levers with motor cutoff switch.
27.5" * 2.8" CHAOYANG tires; tire pressure marked on sidewall.
Air suspension alloy fork, adjustable; 120MM travel distance.
52T * 170MM; single-sided chainring guard
LTWOO, 9-speed, 11-32T.
Comfort rubber ergo grips.
YC-B100 rise handlebar.
Wellgo(B087B) aluminum pedals with reflectors, polymer bearing.
Intergrated threadless headset.
Aluminum leg with durable plastic cover, adjustable.
Comfort leather saddle.
Aluminum 36H spoke wheel.
Aluminum seapost with clamp.
